1. Which flow meters are non-contact? Non contact flow meters include ultrasonic flow meters and radar flow meters. The ultrasonic Youqin flowmeter is widely used and has strong penetration power.

2. Water online monitoring equipment - Detailed explanation of pipeline ultrasonic flowmeter equipment

Pipeline ultrasonic flowmeter is a device based on ultrasonic technology to achieve online monitoring of fluid flow. It calculates flow velocity and flow rate by measuring the propagation characteristics of ultrasonic waves in the fluid, and has the advantages of non-contact measurement, high accuracy, low pressure loss, etc. It is widely used in urban water supply, sewage treatment, environmental monitoring and other fields.

1. Working Principle The core principles of pipeline ultrasonic flowmeter include time difference method and Doppler effect method, which are respectively applicable to different fluid scenarios: time difference method is suitable for pure fluids (such as tap water and industrial liquids).

. By installing a pair of ultrasonic transducers upstream and downstream of the pipeline, alternating the transmission and reception of ultrasonic signals. When ultrasound propagates in both forward and reverse directions, a time difference (Δ t) is generated due to the influence of flow velocity. The flow velocity (V) is calculated using the formula V=(D/(2 * sin θ)) * (Δ t/t?), where D is the diameter of the pipeline, θ is the angle of ultrasound propagation, and t? Is the static propagation time. Calculate the flow rate (Q) by combining the cross-sectional area (S) of the pipeline with Q=V * S. The Doppler effect method is applicable to fluids containing solid particles or bubbles, s Non contact flowmeter

uch as sewage, mud, and natural rivers. The probe emits ultrasonic waves obliquely upwards, and when it comes into contact with impurities or bubbles in the fluid, the reflected waves produce a Doppler frequency shift (Δ f), which is proportional to the flow velocity (V ∝ Δ f). By combining the liquid level height measured by the pressure sensor with the preset pipeline parameters, the cross-sectional area (S) is automatically calculated, and the flow rate is finally obtained through the velocity area method (Q=V * S).

2. Equipment Types and Applicable Scenarios According to the measurement principle and fluid characteristics, ultrasonic flowmeters can be divided into the following types, corresponding to different application scenarios: Time difference method. Ultrasonic flowmeters are suitable for pure fluid scenarios such as urban fracturing water supply pipelines, industrial circulating water, and clean energy transportation.

. Advantages: High measurement accuracy (up to ± 0.5%), strong stability, suitable for large-diameter pipelines (DN15-DN6000). Limitations: High cleanliness requirements for fluid, impurities or bubbles can cause signal attenuation. Doppler ultrasonic flowmeter is suitable for use in natural rivers, agricultural channels, urban sewers, corporate sewage outlets, sewage treatment plants, and other fluid environments containing impurities. Advantages: It can measure high concentration suspended solids or bubbly fluids and adapt to harsh environments. Limitation: The measurement accuracy is slightly lower than the time difference method (usually ± 1% - ± 2%), and regular calibration is required.

III. Core Advantage Non contact Measurement: No need to cut pipes or insert probes, avoi
